Basic Info

Place of Origin:	Hebei China
Supply Ability:	10000square meters
Certificate:	ISO9001

Product Description

Specifications

Polyester Plain Linear Fabrics
material:100% polyester
weave:plain mesh

Polyester Plain Linear Fabrics

The 2-shed and 3-shed polyester plain fabric is mainly used in special lines,such as paper pulps making,Sulplate pulp packing and cardboard pulp,fiberboard plants as well as colliery,food and medicine as conveyor belt.

Description:

Manufacture Process:

Weaving→Heat-setting→Cutting→ Brush the rubber on the edges→ making the joint

type	wire diameter mm		Density/cm		N/cm Tensile strength		weight Kg/m2	Thickness mm	Aperture warp*weft mm	Mesh/inch warp*weft	Air permeability m3/m2h	CFM 127pa	L/m2/S 200pa	open area %
	warp	weft	warp	weft	surface	joint	weight Kg/m2	Thickness mm	Aperture warp*weft mm	Mesh/inch warp*weft	Air permeability m3/m2h	CFM 127pa	L/m2/S 200pa	open area %
021002	1.0	1.0	2.85	2.65	1600	650	0.60	1.85	2.50*2.77	7.10*7.03	24656	2000	12600	52.55
031002	1.0	1.0	3.2	3.25	1600	650	0.80	1.86	2.12*2.07	8.10*8.20	22251	160	10500	45.9
03902	0.9	0.90	3.9	3.65	1600	650	0.55	1.70	1.66*1.83	9.60*9.30	20000	1250	9000	43.58
05602	0.60	0.60	5.9	5.6	1600	650	0.62	1.1	1.09*1.18	14.98*14.2	18000	1125	8210	42.89
05802	0.80	0.80	5.1	5.3	1600	650	0.89	1.48	1.16*1.08	13*13.5	15840	990	6350	34.09
06652	0.65	0.65	7.4	6.8	1600	650	0.65	1.19	0.70*0.82	18.8*17.3	14400	1190	6350	34.09
06802	0.80	0.80	6.6	6.5	1600	650	0.85	1.45	0.72*0.73	16.8*16.5	11600	725	4600	22.65
06702	0.70	0.70	7	7	1600	650	0.77	1.3	0.72*0.72	17.8*17.8	11000	690	4550
