Product Description

Descriptions:

Material: FR-4/HTG150-180, FR-4/CEM-1/CEM-3/aluminum
Layer: 1-20
Board thickness 0.2-4.0mm
Board thickness tolerance: +/-10%
Copper thickness: 17.5-175um (0.5-5oz)
Minimum trace width: 0.15mm
Minimum space width: 0.15mm
Minimum drilling diameter: 0.2mm
PTH copper thickness: 0.4-2mil (10-50um)
Tolerance of etching: ±1mil (±25um)
V-cut angle: 25, 30, 45 and 60°
Pearl strength of line: e 6lb/inch (e 107g/mm)
Impedance control and tolerance: 50©, ±10%
Twist and wrap: d 0.5%
Soldermask: green, red, blue, white, black, yellow
Surface finish/plating: HASL/lead-free HASL/OSP/goldplating/immersion gold/ENIG
Certificate: RoSH, ISO9001, SGS, UL certificate
File: Protel 99se/P-CAD/Autocad/Cam350

Detailed terms for PCB assembly:

Quantity: prototype and low volume PCB assembly, from 1 boardto 250, is for specialty, but we can handle orders up to 1,000
Type of assembly: SMT and through-hole
Solder type: water soluble solder paste, leaded andlead-free
Components: passives down to 0201 size BGA and VFBGA lead-lesschip carries/CSP double-sided SMT assembly fine pitch to 08 milsBGA repair and reball part removal and replacement-same dayservice
Bare Board size

Smallest: 0.25x0.25 inches

Largest: 20x20 inches
File formats: bill of materials Gerber files pick-N-place file(XYRS)
Type of service turn-key, partial turn-key or consignment
Component packing: cut tape tube reels loose parts
Turn time: same day service to 15 day service
Testing: flying probe test, XRAY inspection AOI test

Material: FR-4/HTG150-180, FR-4/CEM-1/CEM-3/aluminum

Layer: 1-20

Board thickness 0.2-4.0mm

Board thickness tolerance: +/-10%

Copper thickness: 17.5-175um (0.5-5oz)

Minimum trace width: 0.15mm

Minimum space width: 0.15mm

Minimum drilling diameter: 0.2mm

PTH copper thickness: 0.4-2mil (10-50um)

Tolerance of etching: ±1mil (±25um)

V-cut angle: 25, 30, 45 and 60°

Pearl strength of line: e 6lb/inch (e 107g/mm)

Impedance control and tolerance: 50©, ±10%

Twist and wrap: d 0.5%

Soldermask: green, red, blue, white, black, yellow

Surface finish/plating: HASL/lead-free HASL/OSP/goldplating/immersion gold/ENIG

Certificate: RoSH, ISO9001, SGS, UL certificate

File: Protel 99se/P-CAD/Autocad/Cam350

Quantity: prototype and low volume PCB assembly, from 1 boardto 250, is for specialty, but we can handle orders up to 1,000

Type of assembly: SMT and through-hole

Solder type: water soluble solder paste, leaded andlead-free

Components: passives down to 0201 size BGA and VFBGA lead-lesschip carries/CSP double-sided SMT assembly fine pitch to 08 milsBGA repair and reball part removal and replacement-same dayservice

Bare Board size

Smallest: 0.25x0.25 inches

Largest: 20x20 inches

File formats: bill of materials Gerber files pick-N-place file(XYRS)

Type of service turn-key, partial turn-key or consignment

Component packing: cut tape tube reels loose parts

Turn time: same day service to 15 day service

Testing: flying probe test, XRAY inspection AOI test
