solid minerals slurry pump for mining

1. General Description
Transport the slurry with low concentration, PH 5-12, metal lined (also corrosive slurry with rubber lined).
2. Introduction
Type NLM(R) slurry pumps are cantilevered, horizontal, centrifugal, slurry pumps.NLM series pump is light duty slurry pump, which features by higher rotate speed, smaller size and lighter weight compared to heavy duty slurry pump, NLM(R) slurry pumps are suitable for delivering less abrasive, low dense slurry.
The frame plates have changeable, wear-resistant, metal liners or rubber liners and the impellers are made of wear-resistant metal or rubber (Rubber for frame plates, impellers of pumps with discharge Dia. (mm) above 550mm.)The discharge position by request may be rotated 8 different angles at internal of 45 degrees for installation and application.The shaft seals could adopt the Packing seal, Expeller Seal or Mechanical seal.
3. Model Explanation
NLM(R)-100D
N: Our company(Norman)
L: Low concentration
M: Metal lined
R: Rubber lined
100: Discharge size (mm)
D: Frame type with maximum power
