insulation ceramic fiber modules
- Delivery Time:
- 20 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Hebei, China (Mainland) |
|---|
Excellent thermal stability
Excellent chemistry quality
Low thermal conductivity
refractory ceramic fiber modules
Ceramic fiber modules, which all can be processed mechanically,and with the advantage of smoothly surface and anterode,no fiber rupture ,our products with advanced RX2 anchor system, the fixing operation easy ,quick,and efficiently , Products are divided into: common , high pure, high aluminum zirconium type aluminum silicate ceramic fiber module. Ceramic fiber moudles specification STD 1260 Ceramic Fiber Board HP 1260 Ceramic Fiber Board HA 1360 Ceramic Fiber Board HZ 1430 Ceramic Fiber Board Ceramic fiber moudles application 1. Petrochemical furnaces, cracking furnaces . 2. Steel industry furnace, annealing furnace. roller hearth furnace, etc. 3. The aluminum industry are hot furnace, furnace are Ceramic, industry tunnel kilns,intermittent kilns. 4. Waste recycling, combustion chamber. 5. High-end household appliances insulation device.
Ceramic fiber moudles technical data ITEM | Standard | Pure | High Aluminum | Zirconium | |
Classification temperature(℃) | 1260 | 1260 | 1360 | 1430 | |
Work temperature(℃) | 1050 | 1100 | 1200 | 1350 | |
Color | white | white | white | white | |
Density(kg/m3) | 200/220 | 200/220 | 200/220 | 200/220 | |
Permanent.linear shrinkage(%) | -3 (1000℃) | -3 (1100℃) | -3 (1250℃) | -3 (1350℃) | |
| Thermal conductivity (w/m.k) | 0.09(400℃) 0.176(800℃) | 0.09(400℃) 0.176(800℃) 0.22(1000℃) | 0.132(600℃) 0.22(1000℃) | 0.76(600℃) 0.22(1000℃) | |
Tensile.strength(Mpa) | 0.08-0.12 | 0.08-0.12 | 0.08-0.12 | 0.08-0.12 | |
|
Chemical Composition(%) | AL2O3 | 46 | 47-49 | 52-55 | 39-40 |
| AL2O3+ SIO3 | 97 | 99 | 99 | - |
| AL2O3+SIO3+ ZrO2 | - | - | - | 99 |
| ZrO2 | - | - | - | 15-17 |
| Fe2O3 | <1.0 | 0.2 | 0.2 | 0.2 |
| Na2O + K2O | ≤0.5 | 0.2 | 0.2 | 0.2 |
Size(mm) | 600x(240-300)x(100-200)without anchor, 300x300x200/250with anchor, other size up to your demand | ||||
Package | Carton | ||||
Ceramic fiber moudles features • Low thermal conductivity, low thermal capacity • Excellent thermal stability and good resistance to heat shock • Excellent tensile strength • Good anti-stripping performance • Good Sound-absorbing performance • Non-brittleness material, good flexibility • Excellent machining performance • Resistance to wind and erosion,long service life • Excellent heat insulation, fire prevention, sound absorption performance
