non-combustible fireproof insulating vermiculite panel

Specifications Non-combustible and fire resistant.

Excellent thermal insulation properties

Eco-friendly

Easy to cut and shape


  Our VMC Vermiculite panel is a non-combustible board made from the expanded vermiculite and inorganic binder. It contains non mineral or glass fibers or asbestos. It is both ecological and resistant to temperatures up to 1100℃ The boards feature good sound-absorbing and thermal insulating properties. Another advantage of the vermiculite boards is that they are easy to work using the normal wood-working tools. Various surface finishes can also be applied to the surface easily.       VMC-FP Main application:  used as fire door cores, fire-resistant walls and ceilings, fire protection cladding for structural steels, fire protection for air-conditioning and cable trays etc.     VMC-FR Main application:  as insulation in reduction cells ,as back-up insulation in all types of furnaces (from carbon baking furnaces to remelting of scrap), replacement fire brick for wood burning or multifuelstoves etc.   VMC-SA Main application:  as acoustic ceilings and walls

Vermiculite Panel Technical Date
Bulk density (Kg/m3)		400	500	600	700	800	900
Maximum service temperature (‘C)		1000	1000	1100	1100	1100	1100
Compressive strength (Mpa)		0.8	1.1	1.5	2.0	2.5	3
Total porosity (%)		74	70	67	65	62	60
Liner reheat shrinkage (%) 24H@900’C		<4	<3.5	<3	<2.5	<2.25	<1.9
Thermal conductivity (W/mk)	@200’C	0.1	0.1	0.12	0.13	0.14	0.14
	@400’C	0.12	0.13	0.14	0.15	0.16	0.16
	@600’C	0.14	0.15	0.16	0.17	0.18	0.18
Standard Dimensions (mm)
Length * Width		1000x610		2100x900		2440x1220
Thickness		10-50		20-50		20-50
*Customized shapes also can be supplied according to customer’s drawings
