Galvanized Steel Grating / Stainless Steel Grating / Bar Steel Grating

  Product Description   Steel Grating/ Steel Bar Grating/ Welded Bar Grating   Material: Mild steel, Stainless Steel     such as: Q235, SS304, SS316 Bearing Bar Pitch: 30mm, 40mm, 60mm Cross Bar Pitch: 50mm, 100mm Thickness of the Bearing Bar: 3mm, 5mm Bearing Bar Width: Surface Treatment: Galvanized, painted   Characteristic: High strength, lightstructure; powerful anti-corrosion,durable and long working life; beautiful apperance,bright surface; no dirt-lighting,heat-dispersing, resistance osliding explosion; easy maintenance;good venilation, day-lighting, heat-dispersing,resistance to sliding exposion;easy installation and dis-assembly.     Specification as a reference:

Series	Bearing Bar Pitch	Cross Bar Pitch	Bearing Bar Spcification                                    (Width *Thickness)
	mm	mm	32*5 mm	40*5    mm	45*5 mm	50*5 mm	55*5 mm	60*5 mm
1	30	50	G325/30/50	G405/30/50	G455/30/50	G505/30/50	G555/30/50	G605/30/50
		100	G325/30/100	G405/30/100	G455/30/100	G505/30/100	G555/30/100	G605/30/100
2	40	50	G325/40/50	G405/40/50	G455/40/50	G505/40/50	G555/40/50	G605/40/50
		100	G325/40/100	G405/40/100	G455/40/100	G505/40/100	G555/40/100	G605/40/100
3	60	50	G325/60/50	G405/60/50	G455/60/50	G505/60/50	G555/60/50	G605/60/50
Series	Bearing Bar Pitch	Cross Bar Pitch	Bearing Bar Spcification                                    (Width *Thickness)
	mm	mm	20*3   mm	25*3   mm	32*3   mm	40*3   mm	20*5   mm	25*5    mm
1	30	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
		100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
2	40	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
		100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
3	60	50	G203/60/50	G253/60/50	G323/60/50	G403/60/50	G205/60/50	G255/60/50

  Application:   Platform Steel platform
Stair Grating
Steel Grating Fence
Grating Ceiling
Trench cover Contact Ways: Company Information Haotian Hardware Wire Mesh Products Co.,Ltd is specialized in the production of Temporary Fence series (swimming pool panel,temporary steel hoarding,fence clamp,fence feet,fence barce,etc) Crowd Control Barrier,Mesh Fence,Horse Panel,DogKennel,Gabions,Iron Decorative Mesh Fence with nice design,etc   Our Services 1.Provide free sample for customer. 2.Provides the high quality product and the consummation post-sale service wholeheartedly for the customer. 3.Any inquiries will be replied within 24 hours; And any questions, pls feel free to contact me.
