Excellent Glass Wool covered with aluminum foil/ glass wool with kraft facing

Specifications glass wool insulation

professional factory

density: 10-48kg/m3

thickenss:25-150mm

AS/NZS48591 ,CE ISO 9001

        Excellent Glass Wool covered with aluminum foil/ glass wool with kraft facing                                                                                                                                                                                                                                   Specification       Glasswool is a lightweight, highly resilient insulation made from borosilicate glass fibers. The insulation in blanket, board or tubing is fiber glass bonded with a thermosetting phenolic resin and is designed to provide this product with excellent core strength. The countless air spaces in CH-Fiber create effective sound absorption as well as thermal properties. Perceived noise from air movement and mechanical equipment is noticeably reduced. Glasswool blanket is compression packaged to significantly reduce volume. The result is potential savings in both freight costs and storage.   Data   Glasswool Physical Properties

Features	Unit	Performance	Standard
Density	kg/m3	10 ~ 100	GB/T 5480.3-1985
Average fiber diameter	μm	5.5	GB/T 5480.4-1985
Water conten	%	≤1	GB/T 3007-1982
Combustibility performance		Non-combustible Grade A	GB 8624-1997
Reshrinking temperature	°C	≥250	GB/T 11835-1998
Thermal conductivity	w/m·K	0.038-0.06	GB/T 10294-1988
Hydrophobicity	%	≥98.2	GB/T 10294-1988
Moisture rate	%	≤5	GB/T 16401-1986
Sound absorption coefficient		24kg/m3 2000HZ	GBJ47-83
Slag inclusion content	%	≤0.3

        Product specifications of

Product	Length (m)	Width/Diamete (mm)	Thickness (mm)	Density (Kg/m3)
Board	1.2-2.2	600 ~ 1200	20 ~ 100	24 ~ 96
Roll	11.0 or 22.0	1200	25 ~ 150	12, 16, 20, 24, 32, 40, 48
Pipe	1.0	Φ 15 ~ 400	20 ~ 100	45 ~ 90

      Main indexes of physical properties of refractory fiber glass

Features	Unit	Performance	Standard
Density	kg/m3	10 ~ 80	GB/T 5480.3-1985
Average fiber diameter	μm	5	GB/T 5480.4-1985
Combustion performance		Non-combustible Grade A	GB 8624-1997
Reshrinking temperature	°C	500	GB/T 11835-1998
Thermal conductivity	w/m·K	0.041 ~ 0.07	GB/T 10294-1988
Hydrophobicity	%	≥99	GB/T 10294-1988

      Delivery information MOQ: 1X20"FT, 1X40"HQ Delivery Time: Within 7-15 days after received advance Payment: T/T, L/C, DP & DA and we can discuss.        Loading picture show:        Test Report Certificate:  AS/NZS4859.1 , CE, ISO           Our Company Mission: Help partners to achieve success. Cooperaion wih customers to create a win-win situation. We will guarantee the best quality and service let you more satisfied.         When you have free time, welcome to visit our factory any time.
