Elastomeric thermal insulation rubber foam

1. Closed-cell Structure.

2. Low and Stable Thermal Conductivity.

3. Low Water Absorption Rate.

4. Good Fireproof and Soundproof Performance.

5. Good Aging Resistance Performance.

6. Simple and Easy Installation.

7. Environmental friendly & Improved IAQ.

Be used to retard heat transmission and control condensation from chilled-water and refrigeration systems. It also efficiently reduces heat transfer for hot-water plumbing and liquid-heating and dual-temperature piping

It is ideal for applications in:

Ductwork

Dual temperature and low pressure steam lines

Process piping

Air-conditioner, including hot gas piping

Property

Unit

Value

Density range

kg/m³

50~100

Flammability

     -

B1

Oxygen index

%

≥33

Thermal conductivity

 -

-

Average tempreture

-20°C

0°C

40°C

w(m.k)

≤0.032

≤0.035

≤0.037

Moisture resistance factor

    -

≥5x10³

Water absorption ratio in vacuum

%

≤10

Dimension stability

105°C ±3°C, 7d

-

≤10

Ozone resistance

200h

%

Good, not cracking

Compress resilience ratio

Compression ratio 50%

Compression time 72h

%

≥70

Aging resistance

-

150 hours, slight wrinkles, no cracks, holes or distortion

Dimensions

-

Pipes/tubes are in 1.83 mtr or 1.85 mtr length

Sheet in rolls 1 mtr or 2 mtr width
