aluminum foil rubber foam insulation roll sheet

Specifications aluminum foil rubber foam insulation

1. professional factory

2. full-closed structure

3. great fireproof

4.CE,SGS, RoHS

aluminum foil rubber foam insulation roll sheet   Product Description   Crown Rubber foam plastic Insulation : Main specification range:
Length: 9m-30m
Width: 1m,1.2m Thickness: 6mm,9mm-30mm We also can make special production according to clients' specification We got the CE, ISO, Certificate for our CROWN Brand Rubber Foam plastic.   Product specifications: Rubber plastic board (1m wide)

Thickness		6mm	9mm	15mm	18mm	20mm	25mm	28mm	30mm
m/pcs		20m	20m	10m	10m	10m	8m	8m	8m

It can be ordered to produce if there is big demand of board with thickness of 13mm, 18mm, 23mm or 28mm. Rubber plastic pipe ID: 6-108mm thickness 9-30mm length:1.8 1.9 2.0m Technical Specifications of NBR/PVC:

Item		Unit	Specification	Standard
Density		Kg/m³	≤95	GB/T6343
Flammability	Oxygen index	%	≥32	GB/T2406
	SDR	——	≤75	GB/T8627
Conductivity factor Average temperature -20°C 0°C 40°C		W/(m.k)	≤0.031 ≤0.034 ≤0.036	GB/T10294
Watervapor permeability	Coefficient	g/(m.s.pa)	≤2.8*10-11	GB/T17146-1997
	Factor	——	≥7.0*10³
Water absorption ratio in vacuum		%	≤10	GB/T17794-2008
Dimension stability 105±3°C,7d		%	≤10	GB/T8811
Crack resistance		N/cm	≥2.5	GB/T10808
Compression resilience ratio Compression time 72h		%	≥70	GB/T6669-2001
Anti-ozone Ozone pressure 202mpa 200h		——	Not cracking	GB/T7762
Aging resistance 150h		——	Slightly crumpling, no cracks,	GB/T16259
Temperature		°C	-40°C——110°C	GB/T17794

  Packaging & Shipping production line: We are export over sea about 6 years !Around 1000x40'HQ ! Our samples is free. If you have time, welcome to visit our factory.   Company Information Judy: TEL: (0086)13383112927 Ph: (0086) 18034598880 Skype: supersale003 QQ: 2220612366 Website: www.crownglasswool.com
