DX factory hot sell HF plane board jointing machine with CE/ISO

Product Description   46 HF Plane board jointing machine  Applied for spliciing of integrated material , door edge gluing , door pocket edge gluing , L door pocket assembly , splicing of door panel .         Specifications :

Type	VHBPB-28P	VHBPB-46P	VHBPB-65P	VHBPB-83P	VHBPB-91P
Workbench size (mm)	2500X1300	2500X1300	2500X1300	2600X1300	2300X1300
Splicing thickness(mm)	10-50	10-80	10-150	10-180	15-200
Upper pressure( T)	9	13	13	13	21
Back pressure ( T)	19	33	52	70	70
Overall dimension (mm)	8700*2300*2300	8700*2350*2300	8700*2350*2300	8800*2350*2300	8500*4400*2300
Weight ( T)	3.5	5.5	6.5	7	9
Feeding mode	AUTO	AUTO	AUTO	AUTO	AUTO

        Packaging & Shipping     Packaging :Standard export packing, plastic and foam, fixed by wood pallet, shipped in container by sea .   Shipping : 15-20days     Certifications           Our Services   The warranty time is one year for whole machine ,    We will be free to maintain machine for user in whole service life.       Our contact infos   Daxin Electronic Science And Technology Co., Ltd  Email : haibo10(at)vhaibo.com   Skype : xiaoyao101802(at)outlook.com Phone :17731181474 QQ : 630191463 Contact person : Ms Vivian
