Compact Structure Timber Drying Kiln Of Authentic Quality

Specifications High frequency vacuum timber dryer

1.3-10 cubic meter volume

2.Quick heating

3.Fast drying new drying method

High frequency vacuum wood dryer machine Two main parts of the machine: 1) High frequency generator 2) Vacuum wood dryer oven To meet the specification of wood with the length 5.5-6m, the width 1-1.2m and height 0.7-1m High Frequency Vacuum Wood Dryer Machine is the result of design combining High frequency medium heating technology and Vacuum cryogenic dehydration technology. The working principle of HF medium heating: in the high frequency electrical filed, friction of medium molecule generates heat. Keeping the wood in the frequency electrical filed, thus the inside & outside of wood will be rapidly heating. Meanwhile, vaporizing temperature of water will be decreased under vacuum conditions.  Specification Technology data (3 cubic meters): 1. Capacity of dry oven: 3 cubic meters 2. Vacuum degree: 0——-0.093Pa or according to the need 3. Drying temperature: ≤90°C 4. Final moisture content of wood: 18%-20% or could be setting as per-request 5. Maximum dehydration rate: 90 KG / 24 hours 6. Power of high frequency machine: 10KW 7. Frequency of high frequency machine: 6.78MHz 8. Power input of vacuum pump: 4KW 9. Maximum input total power: 13KVA Technology data (8 cubic meters): 1. Capacity of dry oven: 8 cubic meters 2. Vacuum degree: 0——-0.093Pa or according to the need 3. Drying temperature: ≤90°C 4. Final moisture content of wood: 18%-20% or could be setting as per-request 5. Maximum dehydration rate: 220KG / 24 hours 6. Power of high frequency machine: 30KW 7. Frequency of high frequency machine: 4MHz 8. Power input of vacuum pump: 4KW Maximum input total power: 40KVA Technology data (10 cubic meters): 1. Capacity of dry oven: 10 cubic meters 2. Vacuum degree: 0——-0.093Pa or according to the need 3. Drying temperature: ≤90°C 4. Final moisture content of wood: setting as per-request 5. Maximum dehydration rate: 310KG / 24 hours 6. Power of high frequency machine: 40KW 7. Frequency of high frequency machine: 4MHz 8. Power input of vacuum pump: 4KW 9. Maximum input total power: 50KVA Package: Standard export packing, plastic and foam, fixed by wood pallet, shipped in container by sea
