High frequency power supply and wood Vacuum plant

Specifications experienced Lumber dry kilns

1)Effective capacity: 3-10cbm

2)No cracking, no bending

3)Especially for hard wood

Lumber dry kilns -High frequency vacuum dryer (timber dryer)
1. It is new drying method. (Dielectric heating)
Steam and normal vacuum dryer(hot plate) is conductive heating.
They dry the wood little by little from outside to inside.
High frequency is dielectric heating. HF wave can penetrate the thick wood
And dry it uniformly. Even the core of wood temperature is heater than surface.
Vacuum condition: It is minus pressure, safe.
The wood moisture can vaporized in low temperature.
Then vapor will be pump out automatically.
So HF vacuum dryer is faster, more uniform, no bending and no crack caused by non-uniform.
2. No need boiler; No need hot plate (no hot water)
The power supply of HF vacuum dryer is electricity.
It does not need boiler, save the human resource and protect the Environment.
3. Worm killing.
High frequency can kill the worm and bacteria.
It does not need special chemical treatment.

Specification	HF machine power	Effective volume	Wood species	Wood maximum length	Shape dimension (mm)	Inner space (mm)	Timber cart (mm)
GZ-3.0 II-DX	10KW	3.3m³	All wood	3M	4330 *1716 *1806	3600 *1500 *1500	3000 1100 1000
GZ-4.0 II-DX	10KW	4.4m³		4M	5330 *1716 *1806	4600 *1500 *1500	4000 1100 1000
GZ-6.0 II-DX	20KW	6m³		5M	6465 *1916 *2006	5600 *1700 *1700	5000 1200 1000
GZ-8.0 II-DX	30KW	7.8m³		6M	7605 *2016 *2006	6600 *1700 *1700	6000 1200 1100
GZ-10.0 II-DX	50KW	10.8m³			7500 2140 2240	6600 *1900 *1900	6000 1500 1200
