gabion boxes and mattresses(Factory price)

Specifications SpecificationsMaterial:Hot-dipped/Electric Galvanized,Low-carbon Steel,Iron Wire,etcProcess: WeldedISO 9001:2008

Gabion Basket Wire  All tests on wire must be performed prior to manufacturing the mesh. All wire should comply with ASTM A975- 97, style 3 coating, Galfan and PVC coated steel wire. Wire used for the manufacture of Gabions and the lacing wire, shall have a maximum tensile strength of 75 000 psi (515 MPa) as per ASTM A856-03, soft temper steel. Features · Economic. · Just fill the stone into the Gabions and seal it. · Simple installation. · No special technology needed.Weather proof under natural destroy, corrosion resistant. · No collapse even under big scope of deforming. · Sludge in the stones is good for plant growing. · Mixed to form a integrity with the natural environment.Good permeation can prevent the damage by hydrostatic. · Less transport freight. It can be folded together for transport and further installation. Gabion Baskets applications · Control and guide of water or flood · Flood bank or guiding bank · Preventing of rock breaking · Bridge Protection · Water and soil protection · Coast protection · Seaport engineering · Strengthening structure of soil · Protection of road                                                                                                                                          WIRE THICKNESS SPECS

Characteristics	Metallic coated	PVC coated	Metallic coated	PVC coated
Mesh type	8*10cm		6*8cm
Mesh openings	83mm x 114mm 8 x 10	83mm x 114mm 8 x 10	64mm x 83mm 6x8	64mm x 83mm 6x8
Mesh wire	2.7mm  (0.106 in.)	3.05mm( 0.120 in.)	2.2mm (0.087 in.)	2.2mm (0.087 in.)
Selvage wire	3.4mm (0.134 in.)	3.8mm (0.150 in.)	2.7mm (0.105 in.)	2.7mm (0.105 in.)
Lacing wire	2.2mm (0.087 in.)	2.2mm (0.087 in.)	2.2mm (0.087 in.)	2.2mm(0.087 in.)

 Size of gabion box and size of gabion mattress

Gabion Box
Opening    (mm)	Wire Diameter(Metal Wire)                   (mm)	Wire Diameter (PVC Coated)/          Inner/Outside(mm)	Strands
60X80	f2.0-2.8	f2.0/3.0-2.5/3.5	3
80X100	f2.0-3.2	f2.0/3.0-2.8/3.8	3
80X120	f2.0-3.2	f2.0/3.0-2.8/3.8	3
100X120	f2.0-3.4	f2.0/3.0-2.8/3.8	3
100X150	f2.0-3.4	2.0/3.0-2.8/3.8	3
120X150	f2.0-4.0	2.0/3.0-3.0/4.0	3



Size				Notes	tolerance
length(m)	width(m)	high(m)	(unit)	volume(m3)	Length±3%    Width±5%    High±5%
2.00	1.00	0.30	1	0.60
3.00	1.00	0.30	2	0.90
4.00	1.00	0.30	3	1.20
2.00	1.00	0.50	1	1.00
3.00	1.00	0.50	2	1.50
4.00	1.00	0.50	3	2.00
1.00	1.00	1.00	0	1.00
1.50	1.00	1.00	0	1.50
2.00	1.00	1.00	1	2.00
3.00	1.00	1.00	2	3.00
4.00	1.00	1.00	3	4.00

        Notice:   Our samples free, welcome to visit our factory   We promise : cost price for the first cooperation   Our advantages:   a.We are the manufacturer, not only trading company, price will be much competitive   b.We have produced strickly in according to the customers’ request.   c. We adhere to the operational theme of “good Quality , high Credibility and best Service".
