Galvanized Triple Torsion Wire Mesh

Specifications Triple Torsion Wire Mesh

ISO9001:2008

Wire Diameter:BWG14-BWG24

Hole Size:1/2'-4"

(Hot dip/electro)galvanized,PVC coated

Galvanized Triple Torsion Mesh ---HOT SALE !          Product Description   Hexagonal Wire Netting is also known as Chicken Netting, or Hexagonal Wire, triple torsion mesh. Our  factory produces hexagonal wire mesh in three varieties: galvanized iron, PVC coated and stainless steel.         Wire Materials: Quality mild steel wire, stainless steel wire, etc.
Weaving Patterns: Straight twist, reverse twist, double twist.
Process: Galvanized after weaving or galvanized before weaving.     Finish of Triple Torsion Wire Mesh : Electric galvanizing, hot-dip zinc plating, stainless steel.     Standards Item:   Tolerances:  Dimensions: ± 5% in length, wide and high. weight ± 5%

Triple torsion mesh:Normal Twisted
Roll length: 5m,10m,25m,30m,100m,Width: 0.5m-2.0m or as request.
MESH		WIRE GAUGE
INCH	MM	BWG)
3/8"	10MM	27,26,25,24,23,22,21
1/2"	13MM	27,26,25,24,23,22,21,20
5/8"	16MM	27,26,25,24,23,22
3/4"	20MM	25,24,23,22,21,20,19
1"	25MM	25,24,23,22,21,20,19,18
1-1/4"	30MM	22,21,20,19,18
1-1/2"	40MM	22,21,20,19,18,17
2"	50MM	22,21,20,19,18,17,16,15,14
3"	75MM	21,20,19,18,17,16,15,14
4"	100MM	17,16,15,14
Triple torsion mesh:Reverse Twisted
Roll length: 5m,10m,25m,30m,100m,Width: 0.5m-2.0m or as request.
MESH		WIRE GAUGE
INCH	MM	(BWG)
1"	25MM	22,21,20,19,18
1-1/4"	30MM	22,21,20,19,18
1-1/2"	40MM	20,19,18,17
2"	50MM	20,19,18,17,16
3"	75MM	20,19,18,17,16

    Packaging & Shipping      Packaging:   1)shrink film+ label (customer’s logo is ok )   2) water-proof paper+ shrink film+ label   3) water-proof paper+ shrink film+label, then in cardboard carton   4) water-proof paper+ shrink film+label, then in pallet.   5) water-proof paper+ shrink film+label ,then in wooden case.     Each roll shrink wrapped or packed with water-proof paper. box, carton, pallet. special packing method may be acceptted after confirmation.     Product Uses      For Keeping animal   Keeping rabbit, poultry, small or large animal in park or wild       For River protection Enginnering     RETAINING WALLS
The walls of Fasciones are designed to maintain a difference in the ground levels in their two sides constituting an important group of elements of support and protection when it is located in beds of rivers.     GROUND CONSERVATION
The accelerated hydric erosion is considered extremely detrimental for grounds, due to this one phenomenon, great fertile ground surfaces are lost; since the solid material that is given off in the parts middle and high discharge of the river basin, causes the saturation of the hydraulic infrastructure, electrical, agricultural and of communications that exist in the low part.     RIVERS CONTROL
In the rivers, the gabion accelerates the state of balance of the channel. It avoids erosions, transport of materials and collapses of margins, in addition the fascione controls crescents protecting valleys and populations against floods .         Company Information       Our Services     We are the one team- we supply full suggest solution for clients.   LIKE MAYDAY ONE TEAM MAKE THE WORLD PERFECT   I am Ms J, here wait for you  :)
