widely used spiral paper tube making machine

Specifications China popular sales automatic spiral paper tube machine supplier

PLC implement central control.

Process different thickness

Spiral paper tube machine  & slitting machine & Spiral paper tube machinery     We offer efficient high speed core winder with multi cutter which is used extensively to cut the tubes into small and large sizes while working on-line with the main spiral tube winder.   These are easy to operate and its cutting carriage moves freely on the slide synchronized with the main tube winder.   It has pre-set knives which are used to cut the tubes to the selected widths and the recut tube is delivered. These machines come with the following     Hebei Lvjoe Machinery Manufacturing Co., Ltd. is professional in designing and manufacturing all kinds of industrial equipments. Our company has 186 workers, more than 80 sets of processing machines, including 2 sets of planer machines, one set of milling machine, 2 sets of boring machines, 50 sets of lathes and 3 sets of PLC processing centers.

    specification:

Applicable Technical Parameters		Machine Consists
Tube I.D.	76-500mm	Paper reel stand	ZT Type
Tube wall thickness	5-15mm	Cascade glue unit	PL type
Paper plies	Can be adjusted depends on paper and tube wall thickness, generally 420GSM= 0.6mm thickness/ ply	Spiral winding part	Two drums
Paper gramme	250-530GSM	In-line cut off unit	Single saw blade unit
Machinery speed	1-12m/min  (depend on tube sizes, material quality and operator skill )	Bottom-ply stand	For the inner ply
Machine Functions:
1. Adopt hang-type operation panel, more convenient;
2. Adopt infrared ray set cut length, convenient and accurately;
3. Mechanical loading paper reels, reduce labor force;
4. Paper ply tension control system, cylinder press paper ply firmly, adjust tension freely;
5. With glue pots and pressure tension control system; adopt single or double side gluing depends on tube strength requirement;
6. Flanged shaft with flexile design, suit with tapered mandrel;

    paper tube machine:         1600A slitting machine:     automatic paper core cutting machine:
