Fully Automatic Adhesive Stationery Bopp Tape Slitting Machine

Specifications Bopp Tape Slitting Machine

Unwind diameter: 800mm---1000mm

Rewind diameter: 120---500mm

Bopp Tape Slitting Machine     Features:        Using four shafts for rewinding without stopping the machine. Equipped with 3 sections length counter, can automatically slow down and stop the machine from high speed.   Penumactic control for unwinding tension , double controlled rewinding tension .   Adjustable tension. Equipped with arc stretching roller that can stretch material effectively.     Technical parameters:

Effective width (mm)	1300
Max unwinding diameter (mm)	600
Max rewinding diameter (mm)	4shafts exchange 76.2-150
Min cutting width (mm)	12
Inside diameter of paper tube (mm)	76
Mechanical speed (M/min)	0-180
Size (mm)( L×W×H)	2350×1250×1500
Power of the machine(KW)	4

          Technical parameters:

valid width		1000mm/1300mm/1600mm
Max. unwinding diameter		600mm
slitting width		12-1280mm
I.D of paper core		76.2mm
rewinding I.D	four shafts rewind	76.2-150mm
	two shafts rewind	76.2-300mm
blade		0.2*22*60mm
machine speed		0-180M/min
main motor		5HP
