BULK TUBE A53

Specifications BULK TUBE A

A106 GR B Seamless carbon steel pipe :

Material : carbon steel , stainless steel and alloy steel,

  BULK TUBE  A53   A106 gr b Seamless steel pipe
Outer diameter 6-610mm
wall thickness2.5-40mm
Material 10# 20# 45# 16Mn Q235 Q345 Q219.20G,12Cr1MoVG Seamless steel pipe 1) Application:   Petroleum,chemical,power,gas,metallurgy, shipbuilding, construction, etc
2) Materials:  20#,35#,45#,20G,20MnG,20A,A106B,A106C,ST45.8-III,12CrMo,15CrMo,35CrMo,12Cr1MoV,Cr2Mo,12Cr2Mo,Cr5Mo,A335P12,A335P11,A335P22,A335P5,A335P91, STPA22,STPA23,STPA24,STPA25,STPA26,13CrMo44,10CrMo910,12CrMo195 and so on. 3)Pipe according to standard: ASTM.DIN,BS,GB,API5L,API5CT. 4)Packing: By bundles, seaworthy wooden cases, steel framed cases, and simple packaging or according to the demand of the customers. 5)Delivery time: 25-30days after the shippment.   Outer Diameter: 10~680mm
WT: 2.5~60mm
Length: Maximum of 11.8m

Product	Standard	Steel Grade	Application
Line Pipe	API 5L, ASTM A53/A106, DIN1629, JIS G3454, JIS3466	A, B, X42, X46, X52, X56, X60, X65, X70, St37,ST52	Transmission of the petroleum, natural gas and water
Cylinder Pipe	GB18248	34Mn2V, 37Mn, 30CrMo, 34CrMo4	Raw material for producing cylinder
Boiler Tube	ASME SA106, ASME SA210, ASME SA213, ASME SA335, DIN 17175, GB3087, GB5310	A, B, V, T11, T12, T22, T91, St35.8, St45.8, 20#, 20G, 20MnG, 20MoG, 15CrMoG, 12Cr1MoVG	Low & medium & high pressureboiler header, steam pipe, heating pipe
Structure Pipe	ASTM A53/A106, GB8162	A, B, 20#, 45#, Q345, 20Mn2, 42CrMo	Used for producing mechanical parts and pipe fittings
Hydraulic Tube	GB17396	35#, 45#, 27SiMn, 20CrMo4, 30CrMo4	Mining machinery
Oil Cracking Tube	ASME SA213, GB9948	T5, T9, 20#, 16Mn, 12CrMo, 15CrMo	Used in petroleum cracking furnace
Chemical Pipe	GB6479	20#, 16Mn, 12CrMo, 15CrMo	High pressure chemical equipment and tube

  Seamless Steel Pipe(SMLS) is made from a solid round steel billet which is heated and pushed or pulled over a form until the steel is shaped into a hollow tube. The seamless pipe is then finished to dimensional and wall thickness specifications in sizes from 1/8'' to 36'' OD.

Models of steel pipes	Tensile strengthMPa	Yield strengthMPa	Elongation
20	390min	245min	20min
45	590min	335min	14min
16Mn(Q345B)	490min	325min	21min



Models of steel pipes
	C	Si	Mn	P	S	Cu	Ni	Cr
20	0.17-0.24	0.17-0.37	0.35-0.65	0.035max	0.035max	0.25max	0.25max	0.25max
45	0.42-0.50	0.17-0.37	0.50-0.80	0.035max	0.035max	0.25max	0.25max	0.25max
16Mn(Q345B)	0.12-0.20	0.20-0.55	1.20-1.60	0.035max	0.035max	0.25max	0.25max	0.25max
