Carbon Filter Housing High Quality Pressure Vessel
- Payment Type:
- L/C, T/T, D/P, Paypal, Money Gram, Western Union
- Incoterm:
- FOB, CFR, CIF
- Min. Order:
- 5 Piece/Pieces
- Min. Order:
- 5 Piece/Pieces
- Delivery Time:
- 10 Days
- Transportation:
- Ocean, Land, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 41666/Month |
| Supply Ability: | 500000/Year |
| Payment Type: | L/C,T/T,D/P,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CFR,CIF |
| Certificate: | NSF/PED/ISO |
| Transportation: | Ocean,Land,Air |
Carbon Filter Housing High Quality Pressure Vessel
Working Requirement:
1)Pressure:
· Max operating pressure is 100psi
· Max bursting pressure is 232psi
· Max testing pressure is 150psi
2)Operation temperature:1~ 49°C
3)volume:1~127 mm Hg ( 5" Hg)
4)Capacity: 0.2-100T/H
Carbon Fiber Pressure Vessels Detail:
Carbon Fiber Pressure Vessels Classification :
Residential(6"-13")
Light Commercial(14"-24")Industrail(30"-63")
Carbon Fiber Pressure Vessels Features:
l Excellent mechanical and physical properties;
l Good thermal and electrical insulation;
l Resistance to chemical corrosion, long service life;
l Great design flexibility, vessel wall structure, excellent performance;
l Smooth surface, easy to clean
l Anti-microbial corrosion;
l Smooth surface, easy to clean
Carbon Fiber Pressure Vessels Material:
(a). inner shell – Polyethylene (PE) seamless one-piece tank liner
(b). Outer shell – Continuous strands of fiber-glass with high strength epoxy resin
(c). Bottom base – FRP reinforced tripod base
(d). Opening – 4" precision injected model with threaded opening for 21 ", 24", 30 ", 36" diameter tanks
(e). Opening – 6 "Aluminum flange (anti-corrosion coating) opening for 36", 42" ,48", 63" diameter tanks
Carbon Fiber Pressure Vessels Working Pressure:
(a) ≤1.0MPa(150PSI)
(C) Working Temperature : ≤49°C
(D) Maximum Vacuum : 127mmHg(5"Hg).
(E) Maximum Temperature : 40C (104F)
(F) Composite VesselCertificates: CE ;NSF ; ISO9001 etc.
(G) Media : water
(H) Warranty: 1 years
Carbon Fiber Pressure Vessels Specification:
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Carbon Fiber Pressure Vessels Color:
Blue, Black, Natural, Grey, Yellow(customize color available)
Carbon Fiber Pressure Vessels Production Process:
Carbon Fiber Pressure Vessels Quality Management:
Carbon Fiber Pressure Vessels Application:
Carbon Fiber Pressure Vessels Factory Introduction:
Carbon Fiber Pressure Vessels Workshop:
Carbon Fiber Pressure Vessels Promise:
