NP Mill Circuit Pump for 450 MCR

$5000.00

≥1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Transportation:: Land, Ocean, Air

Port:: Tianjin, Beijing, Shanghai

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Supply Ability:	4000
Payment Type:	T/T
Incoterm:	FOB,EXW
Certificate:	ISO9000
HS Code:	8413910000
Transportation:	Land,Ocean,Air
Port:	Tianjin,Beijing,Shanghai

Product Description

Severe duty lined pump designed for the mostaggressive duties and provide excellent wear lifeand reliability

The Warman® mill circuit pump series easily manages large size particles in denseabrasive slurries and offers the right combination of ruggedness, durability,hydraulics and materials. From the most difficult mill discharge to water flushedcrusher, the Warman® mill circuit pump series is the best choice.

Design Features

Thick elastomer liners with alloyimpellers provide superior wear lifeon the most difficult cyclone feedand screen feed services

Adjustable side liner maintainsefficiency and extends service life(adjustable while running)

Large diameter, slow turning, highefficiency impellers designed toachieve maximum wear life and lowoperating costs

Large,open internal passagesdesigned to reduce internalvelocities,maximise wear life andlower operating costs

Unique, easily centered stuffing boxreduces gland seal maintenance andextends packing life

Quick wet end exchange minimisesdowntime

Interchangeable elastomer andalloy bolt-in liner offer ease ofliner change-out and reducedmaintenance costs

Ductile iron fully lined outer casingprovides durability, strength, safetyand long service life

Heavy duty construction withthrough-bolt design provides ease ofmaintenance and minimal downtime

Minimal shaft/impeller overhangreduces shaft deflection andincreases packing life

Cartridge-style bearing assemblyallows for maintenance in a cleanenvironment without removal of thepump, resulting in reliable operationand prolonged bearing life

Specifications

Size range (discharge):5" to 34"(125 mm to 850 mm)

Capacities to:100,000 gpm (22,700 m3/hr)

Heads to: 180 ft (55 m)

Pressures to: 130 psi (900 kPa)
