We are chinese company with our own factory. Our factory has advanced machines, many-year experience, trained workers. And our aim is providing you the best service. Roll Shutter Door Roll Forming Machine is one of our main products. Apart of it, we can provide Corrugated Steel Sheet, Trapezoidal Rib Steel Roof Tile, Rock Wool Sandwich Panels and so on. If you are interested in our products, you can contact me.

Specifications:

Main frame 300/350/400mm H beam steel
Control system PLC(The brand can be choose)
Uncoiler system Manual or Hydraulic Uncoiler
Roll Forming Station 12-20 rows rollers
(According to the machine design)
Roller material carbon structural steel with hard chromium
Main part power 3kw-6kw
Hydraulic motor power 3kw-6kw
Scissor material Cr12Mov, herd steel HRC 58-62°C
Thickness tolerance ±1mm
voltage 380V, 50HZ,3 phase
(adjustable by customer needs)
Frame form Mid-plate welded
Driving Method gear
Color blue(adjustable)
weight about 3.5T

Produce process flow

Components

1.Manual un-coiler:to load steel coils

It is controlled by gear wheel oil pump. After filling the hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job. Match equipment: a set of hydraulic tank , a set of hydraulic oil pump, two hydraulic pipes and two sets of electromagnetism valves.

It adopts Taida PLC to control(can make as your requirement). The target piece length is adjustable and digit of it can be adjusted. Computed mode has two modes: automatic and manual one.

5. Cutting Mechanism

It adopts hydraulic drive and automatic location to decide the dimention and cut the target products. Match equipment : one set of cutting tool, one hydraulic tank ,one cutter machine. Stop to cut , Post cut

6. Recieving table:Main framework adopts welded steel and supported roller, and used for transmit and collect the finished products.

Packing&shippment

1.Packing:the main parts will be packed with plastic film then fixed to container by iron wire

2.Shippin:shipped in 30days after receiving the full deposit
