Product Description

Trapezoidal Roof Panel Rolling Forming Machinery

It is easy to operate and can produce steel sheet depend on the profile drawing, and we can also design depend on your requirement .and you can also provide your specification of the machine.

Single Layer Roof Roll Forming Machine

Double Layer Roof Roll Forming Machine

Three Layers Roof Roll Forming Machine

Floor Deck Roll Forming Machine

CZ Purlin Roll Forming Machine

Ridge Cap Roll Forming Machine

Specifications:

Feeding material: PPGI

Thickness of the plate:0.3-0.8mm

Feeding width:1000/1200mm

Machine size: 6200mmX1700mmX1400mm

Diameter of the axle :donwn-Φ80mm/ up-Φ90mm

Rolling material: 45#

Rolling galvanization thickness:0.05 mm

Rolling stages:14-15 stages

Productivity:10-12m/min

Total power:5.5kw +3kw

Voltage:380V 60Hz 3phase or as requirement

Weight:about 4.5T

Base frame:350H steel

Side board thickness:16mm

Cutting blade: Cr12 with heat treatment

Cutting system: Hydraulic cutting system after forming

Control cabinet: PLC and frequency changer in it

Warranty:12 months limited warranty

Delivery: 30 days after receipt of advance payment

Package: Plastic packing and nude in the container

Payment Term: T/T, L/C, Trade assurance

Produce process flow

Components

1. Cutting Mechanism

It adopts hydraulic drive and automatic location to decide the dimention and cut the target products. Match equipment : one set of cutting tool, one hydraulic tank ,one cutter machine. Stop to cut , Post cut

2. Roll-forming M/C: Roller Mareial: 45# steel

Double Layer Roll Forming Machine

3. Hydraulic systerm

It is controlled by gear wheel oil pump. After filling the hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job.

Portable Metal Roofing Roll Forming Machine

4.Computer control cabinet

It adopts Taida PLC to control(can make as your requirement). The target piece length is adjustable and digit of it can be adjusted. Computed mode has two modes: automatic and manual one.
