gabion wire cages rock wall/gabion wire box/gabion metal wire mesh

gabion retaining baskets

galvanizing, PVC coating, Galfan,

Mesh Size: 60*80,80*100,100*120

BV Certificate, ISO certificate

PVC Coated /Galvanized Gabion Wall, which is finally designed with the hexagonal wire mesh through the process of double twisting, can be filled with appropriate rocks or stone materials. The hexagonal wire netting is mainly made from high-quality low carbon steel wire. High grade materials produce gabion retaining walls of superior quality.

PVC Coated /Galvanized Gabion Wall is formed with gabion baskets and it plays a positive role in earth retaining, mud-rock flow prevention, slope stabilization, landslide treatment, and soil erosion control, etc.

PVC Coated /Galvanized Gabion Wallis regarded as a flexible and free drainage system, which can effectively resist the disturbing forces

Technical Note of Gabion Wall:
Mesh Size: 60*80,80*100,100*120,120*150and so on.
Wire Diameter: 2.0-4.0mm
Surface Treatment: hot-dipped galvanizing, galvanizing, Galfan, and PVC coating, etc.

Features of PVC Coated /Galvanized Gabion Wall
1. Environmentally acceptable - the use of local rock and soils for backfill is encouraged, with the subsequent growth of vegetative cover.
2. Flexible - able to settle and move without failure even on unstable soils.
3. Economical - suitable stone is normally found on site or from a nearby commercial rock supply.
4. The gabion retaining wall has a high compressive resistance (rock) and tensile (mesh) strength.
5. The gabion retaining wall allow the free passage of water through the structure, and weep holes are unnecessary.
6. Vegetation can be incorporated within or over the structures to blend in with the local environment.
7. The integrity of a local ecosystem within a river is unaffected by gabions as they allow the free flow of water and growth of plants through their structure.

Usage of PVC Coated /Galvanized Gabion Wall
1. Control and guide of water or flood
2. Preventing of rock breaking
3. Rock fall protection
4. Water and soil protection
5. Bridge protection
6. Strengthening structure of soil
7. Protection engineering of seaside area.
8. Port project
9. Keep off dust wall
10. Roadway protection.

 Picture of Packing

Workshop picuture
