1/2 inch pvc coated galvanized hexagonal wire mesh,chicken wire mesh specifications,anping hexagonal mesh

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Hebei, China (Mainland)

Product Description

Hexagonal chicken wire mesh is commonly referred to as hexagonal netting, poultry netting, or chicken wire.

Material: High quality low carbon steel wire, stainless steel wire

Weaving and characteristics: Normal twisted, reverse twisted. Galvanizing after weaving, Galvanizing before weaving. It is divided to electrical galvanized, hot-dip galvanized, plastic coating, stainless steel,etc. It has the characteristics of corrosion-resisting and oxidation-resisting.

Uses: Hexagonal chicken mesh gardon for bird, chicken mesh, protection etc. Poultry or small animals, housing, agricultural use

Specification

General Specification of Galvanized Chicken Wire Mesh
Mesh			Min. Galv.G/SQ.M	Width	Wire Gauge (Diameter)BWG
Inch	mm	Tolerance(mm)	Min. Galv.G/SQ.M	Width	Wire Gauge (Diameter)BWG
3/8"	10mm	±1.0	0.7mm - 145	2' - 1M	27, 26, 25, 24, 23
1/2"	13mm	±1.5	0.7mm - 95	2' - 2M	25, 24, 23, 22, 21
5/8"	16mm	±2.0	0.7mm - 70	2' - 2M	27, 26, 25, 24, 23, 22
3/4"	20mm	±3.0	0.7mm - 55	2' - 2M	25, 24, 23, 22, 21, 20, 19
1"	25mm	±3.0	0.9mm - 55	1' - 2M	25, 24, 23, 22, 21, 20, 19, 18
1-1/4"	31mm	±4.0	0.9mm - 40	1' - 2M	23, 22, 21, 20, 19, 18
1-1/2"	40mm	±5.0	1.0mm - 45	1' - 2M	23, 22, 21, 20, 19, 18
2"	50mm	±6.0	1.2mm - 40	1' - 2M	23, 22, 21, 20, 19, 18
2-1/2"	65mm	±7.0	1.0mm - 30	1' - 2M	21, 20, 19, 18
3"	75mm	±8.0	1.4mm - 30	2' - 2M	20, 19, 18, 17
4"	100mm	±8.0	1.6mm - 30	2' - 2M	19, 18, 17, 16

Producing

Warehouse

Packing

Different type: welded wire mesh panel for construction

Application

Chicken wire mesh is used in many situations including the stabilization of earth movement and erosion, river control, reservoirs, canal refurbishment, landscaping, retaining walls, Hydraulic Engineering, Roof greening and so on.

Company profile

Diamond group
Establish	Covering area	Annual output	workshop	Distance with loading port	number of staff	engineer
1986	98,000m2	9.85 million square meter	7	400km	300	6
