4x4 fiber mesh, 160gr/m2 for plaster

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Hebei, China (Mainland)

Product Description

Fiberglass Mesh

Fiberglass mesh is made by C-glass or E-glass fibers woven roving as its basis material, and then treated with Acrylic Acid Copolymer liquid. It is an ideal construction engineering material, Strength retention rate> 90%, elongation <1%, the durability of more than 50 years. High elastic modulus 0.4Gpa, is can't reach by other chemical fibers .

Different colors are available.

white, blue, yellow, green, orange, etc.

Different size and weight are available

Main Features of fiberglass mesh

1).good chemical stability. Alkali, acid, water, erosion-resistant cement, and other chemical corrosion resistance.

2).high strength and light weight.
3).good dimensional stability, stiffness, smooth, easy to shrinkage deformation, positioning resistance.
4).good toughness. Better impact resistance.
5).mildew, pest control.
6). fire protection, thermal insulation, sound insulation.

Specification

Specifications of fiberglass mesh
NO.	Specifications	Mesh size (mm)		Yarn density (tex)		Mass g/m2	Tensile strength N/5X20cm
NO.	Specifications	warp	weft	warp	weft	Mass g/m2	warp	weft
1	4×4-75g/m2	4	4	48/2	200	75±3	700	850
2	4×4-145g/m2	4	4	134/2	240	145±5	1500	1500
3	4×4-160g/m2	4	4	134/2	300	160±5	1500	1650
4	4×5-110g/m2	4	5	100/2	360	110±5	1100	1200
5	4×5-145g/m2	4	5	134/2	300	145±5	1400	1400
6	4×5-160g/m2	4	5	134/2	360	160±5	1500	1600
7	5×5-125g/m2	5	5	100/2	340	125±5	1100	1300
8	5×5-145g/m2	5	5	134/2	360	145±5	1450	1600
9	5×5-160g/m2	5	5	134/2	430	160±5	1500	1700
10	10×10-90g/m2	10	10	200/2	300	90±3	900	1200
11	10×10-110g/m2	10	10	250/2	450	110±5	1000	1400

Application

Typical applications of fiberglass mesh.

1).75g / m2 mesh fabric used in the reinforcement of thin slurry, to eliminate small cracks and scattered throughout the surface pressure.

2).110g /m2 mesh cloth is widely used in indoor and outdoor walls, prevent the various materials ( such as bricks, light wood, prefabricated structure) of treatment or caused by a variety of expansion coefficient of wall crack and break.
3). 145g/m2 mesh fabric used in the wall and be mixed in variousmaterials (such as brick,lightwood, prefabricated structures), prevent cracking and scatter the whole surface pressure, especially in the external wall insulation system (EIFS ).
4). 160g /m2 mesh fabric used in insulator layer of reinforcement in the mortar, throuth shrinkage and temperature changes.
