Cooling Tower Fill Film Replacement

$1.00

≥100 Piece/Pieces

Min. Order:: 100 Piece/Pieces

Min. Order:: 100 Piece/Pieces

Transportation:: Ocean, Land, Air

Port:: Shanghai

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	90,000 Pieces/Month
Supply Ability:	90,000Pieces/Month
Payment Type:	L/C,T/T,Paypal
Incoterm:	FOB,CFR,CIF
Certificate:	SGS
HS Code:	3926909090
Transportation:	Ocean,Land,Air
Port:	Shanghai

Product Description

Cooling Tower Fill Film Replacement

CF1900 PVC Cooling Tower Fills is used in counter flow or cross flow cooling tower applications and is available in glued blocks 305mm wide x 305mm high, and either 1830mm or 2440mm long.

That can also be cut to length to your specific requirements, or supplied as loose sheets.

Counter Flow Cooling Tower Fill improve water distribution by splitting the water stream as it descends through the fill pack. CF1900 Cooling Tower Fill splits the water stream 8 times in a 12" (305 mm) vertical path. High thermal performance (high KaV/L) and low pressure drop are simultaneously achieved through engineered flute/microstructure design and the highest manufacturing standards.

Cooling Tower Fill Film ReplacementShows

Cooling tower fills CF1900

PVC Cooling Tower Fills Materials

PVC Cooling Tower Fills Specification

Surface Area	Sheet Spacing	Flute Angle	Sheets Per Ft.	Media Pack Sizes: Depth(D), Width(W), Length(L)
48 ft2/ft3 (157.5 m2/m3)	0.75 in (19 mm)	31°	16	Minimum	Maximum	Standard
				D: 6 in(153 mm) W: 6 in(153 mm) L: 1 ft(305 mm)	D: 24 in(610 mm) W: 24 in(610 mm) L: 12 ft(3658 mm)	D: 12 in (305mm) or 24 in (610mm) W: 12 in (305mm) or 24 in (610 mm) L: 4 ft (1220 mm), 6 ft (1829 mm), 8 ft (2439 mm) or 10 ft (3048 mm)

Benefits of CF1900 PVC cooling tower fill
1.original performance for lowest system operating cost
2.minimum downtime
3. maximum service life
4.operational safety
5.easy maintenance
6.easy cleaning

Packing and Delivery

The pvc cooling tower fill usually be packaged by PE belt and pallet. Some customers request by wooden case, it is possible.

Cooling Tower Fill
