Factory high highway guardrail cold roll forming machine
  • Factory high highway guardrail cold roll forming machine
  • Factory high highway guardrail cold roll forming machine
  • Factory high highway guardrail cold roll forming machine
  • Factory high highway guardrail cold roll forming machine
  • Factory high highway guardrail cold roll forming machine
  • Factory high highway guardrail cold roll forming machine
Factory high highway guardrail cold roll forming machine
Factory high highway guardrail cold roll forming machine
Factory high highway guardrail cold roll forming machine
Factory high highway guardrail cold roll forming machine
Factory high highway guardrail cold roll forming machine
Factory high highway guardrail cold roll forming machine

Factory high highway guardrail cold roll forming machine

  • $15000.00
    ≥1 Set/Sets
Min. Order:
1 Set/Sets
Min. Order:
1 Set/Sets
Transportation:
Ocean
Port:
TIANJIN
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: China
Productivity: 1000sets/year
Supply Ability: 200 Set/Sets per Year
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF
HS Code: 84552210
Transportation: Ocean
Port: TIANJIN
Product Description
Product Description

Specification:

1.material into the leading wheel set to open.
2.Level for the next three to four roll, forming shaft diameter Φ80mm(material 45# by quenching), roll material is GCR15, quenching to HRC58°-62°, hard chromium plated, suppression of thickness 2.5m-3.0m.
3.punching:adopt hydraulic punching(material Cr12 model steel quenching, can be adjusted left and right, front and back)
4.cut off  hydraulic shear(material Cr12 quenching HRC60-62)
5.Total  power:18.5KW
6.Cycoidal reducer power: 15KW
7.Transmission: chain drive, 2-inch single-row chain
8.Coil width: 482mm
9.Hydraulic motor power: 15KW, pression: 20Mpa
10.Unit with frequency control: 5m-12m/min
11.Computer adopt Delta PLC
12.Equipment dimension: 10m*1.2m*1.5m

Factory high highway guardrail machine /cold roll forming machine for highway guardrailFactory high highway guardrail machine /cold roll forming machine for highway guardrail

 Factory high highway guardrail machine /cold roll forming machine for highway guardrail









Our Services



Types profiles metal roof sheet roll forming machine:

Factory high highway guardrail machine /cold roll forming machine for highway guardrailFactory high highway guardrail machine /cold roll forming machine for highway guardrailFactory high highway guardrail machine /cold roll forming machine for highway guardrailFactory high highway guardrail machine /cold roll forming machine for highway guardrailFactory high highway guardrail machine /cold roll forming machine for highway guardrail



Packaging & Shipping

 Factory high highway guardrail machine /cold roll forming machine for highway guardrail







Company Information



Shijiazhuang Yingyee Import&Export Co., Ltd.

YINGYEE is the manufacturer specialized in various cold forming machineries and automatic production lines. We have a wonderful team with highly technology and excellent sales, which offer professional products and related service. We paid attention to quantity and after service, got great feedback and honor from all the clients. We have a great team for after service. We have sent several patch after service team to oversea to finish the products installation and adjustment.

Our products were sold to more than 20 countries already. Also included US and Germany.

Main product :

 Roof roll forming machine

 C and Z purlin roll forming machine

 Downpipe roll forming machine

 Hydraulic decoiler

 Light keel roll forming machine6

 Bending machine

 Shearing machine

 slitting machine

 Roller shutter door roll forming machine



FAQ

Training and Installation
1 We offer installation service local in paid, reasonable charge.
2 QT test is welcome and professional.
3. manual and using guide is optional if no visiting and no installation.

Certification and after service
1. Match the technology standard, ISO producing certification
2. CE certification
3. 12 months warranty since the delivery. Board.

Our advantage:
1. Short delivery period.
2. Effective communication
3. Interface customized.
